Assembly charge not included in price.
Waiver Agreement
| Vehicle Size |
1870X755X1088 mm |
| Weight(Incl. Battery) |
63KG |
| Max Load |
120kg |
| Age |
18~55 years |
| Wheel Base |
1250mm |
| Seat Height |
830mm |
| Ground Clearance |
275mm |
| Max Speed |
85km/h |
| Peak Power |
8kw |
| Max Torque |
340N.m |
| Max Mileage(KM) |
80km (25km/h) |
| Protection Grade |
IPX7 |
| Battery Type |
Lithium-ion NMC Battery M50LT |
| Battery Capacity |
72V 30Ah |
| Charge Current |
10A |
| Charging Time |
3H |
| Motor Type |
LPMSM |
| Rated Power |
4kw |
| Rated Voltage |
72V |
| Controller |
72V Sine Wave Vector Controller
|
| Frame |
Aluminum Alloy Frame |
| Wheel hub |
Front: 19*14 Rear: 18*1.85 |
| Tire |
Off road tire Front: 70/100-19 Rear: 3.0*18
|
| Primary Drive System |
HTD 8M belt 560mm+20mm |
| Secondary Drive System |
420 Chain (106 links) |
| Suspension Travel |
Front-200mm/Rear-85mm |
| Front Brake |
220mm x 2.3mm |
| Rear Brake |
203mm x 2.3mm |
| Handbar |
760mm |
| Communication Port |
RS-485+CAN |
